PMC-340 Digital Three-Phase Energy Meter
Device Introduction |
|
Product Highlight |
|
Typical Application |
|
Related Products
Related Solutions
Specification
Technical Specification
Inputs(L1,L2,L3,N)
Voltage (Un)
220VAC | 230VAC | 240VAC
Overrange (% Un)
120% | 115% | 110%
Range(V)
168-264VAC(Self-powered)
Burden
< 10VA/phase
Direct Input
--
Current (Ib/Imax)
20A/100A
Range
0.4% Ib to Imax
Starting Current(Ist)
0.4% Ib (0.08A)
Minimum Current
5% Ib (1A)
Burden
<4VA/phase
Maximum Wire Size
35mm 2(3AWG)
Maximum Torque
2.5N.m
CT Input
--
Current (Ib/Imax)
5A/6A
Range
(0.1%-120%)In
Starting Current(Ist)
0.1%In
Burden
<0.5VA/phase
Frequency
45Hz-65Hz
Solid State Energy Pulse Output (Selectable-kWh/kvarh)
Pulse Constant
1/10/100/500*/1000/3200/5000* imp/kWh(imp/kvarh)
Isolation
Optical
Max.Load Voltage
80V
Max.Forward Current
50mA
Pulse Width
60-150ms (PMC-340-A)
30-150ms (PMC-340-B)
30-150ms (PMC-340-B)
Communications
Protocol
Modbus RTU
Baud Rate
1200/2400/4800/9600/19200 bps
Maximum Wire Size
1.5mm 2 (16AWG)
Maximum Torque
0.45N.m
RS-485 Port
1
Environmental Conditions
Operating Temp.
-25 °C to + 70°C
Storage Temp.
-40 °C to + 85°C
Humidity
5% to 95% non-condensing
Atmospheric Pressure
70 kPa to 106 kPa
Pollution Degree
2
Mechanical Characteristics
Mounting
DIN-Rail
Unit Dimensions
126x90x65 mm
Shipping Dimensions
165x140x110 mm
Shipping Weight
0.68 kg
IP Rating
IP51(Front), IP30(Body)
Features Summary
Display (Backlit)
B&W (No Backlit)
Type of Measurement
ULN per Phase &Avg.
ULL per Phase&Avg.
Current per Phase &Avg.
Neutral Current (Calc.)
Frequency
kW per Phase & Total
kvar per Phase & Total
kVA per Phase& Total
PF per Phase& Total
kWh lmport/Export
kvarh Import/Export
kVAh Total
ULL per Phase&Avg.
Current per Phase &Avg.
Neutral Current (Calc.)
Frequency
kW per Phase & Total
kvar per Phase & Total
kVA per Phase& Total
PF per Phase& Total
kWh lmport/Export
kvarh Import/Export
kVAh Total
Power Quality
THD Voltage & Current
TOHD Voltage & Current
TEHD Voltage & Current
2nd-31stst Harmonics
K-Factor
Voltage/Current Unbalance
TOHD Voltage & Current
TEHD Voltage & Current
2nd-31stst Harmonics
K-Factor
Voltage/Current Unbalance
Battery-backed Real-time Clock
√
Demands
Present Demands and Max.Demands for This Month & Last Month
Multi-Tariff TOU capability
Two TOU schedules, each providing:
12 Seasons
90 Holidays
20 Daily Profiles, each with 12 Periods in 15-minute interval
4 Tariffs
12 Seasons
90 Holidays
20 Daily Profiles, each with 12 Periods in 15-minute interval
4 Tariffs
Logs
Max./Min.Log
This month & Last Month
Monthly Energy Log
12 months
Data Recorder(PMC-340-B Only)
1 Data Recorders
SOE Log(PMC-340-B Only)
16 entries
On-board Log Memory (PMC-340-B Only)
2MB
Accuracy
Parameters
Accuracy
Resolution
Voltage
±0.5%
0.1V
Current
±0.5%
0.001A
P,Q,S
±1.0%
0.001kW/kvar/kVA
kWh
IEC 62053-21 Class 1
0.01kWh
kvarh
IEC 62053-23 Class 2
0.01kvarh
PF
±1.0%
0.001
Frequency
±0.02Hz
0.01Hz
Standards of Compliance
Safety Requirements
CE LVD Directive 2014/35/EU
EN 61010-1: 2010
EN 61010-2-030: 2010
EN 61010-2-030: 2010
Insulation
AC Voltage
Impulse Voltage
AC Voltage
Impulse Voltage
IEC 62052-11: 2003
IEC 62053-21: 2003
NMI M6-1
4kV @ 1 minute
12kV+0%, -15%, 1.2/50µs (NMI M6-1)
IEC 62053-21: 2003
NMI M6-1
4kV @ 1 minute
12kV+0%, -15%, 1.2/50µs (NMI M6-1)
Electrical Safety in Low Voltage Distribution Systems up to 1000Vac and 1500Vdc
IEC 61557-12:2018(PMD)
Electromagnetic Compatibility EMC 2014/30/EU(EN 61326:2013)
Electrostatic Discharge
EN 61000-4-2:2009
Radiated Fields
EN 61000-4-3:2006+A1:2008+A2:2010
Fast Transients
EN 61000-4-4:2012
Surges
EN 61000-4-5:2014+A1:2017
Conducted Disturbances
EN 61000-4-6:2014
Magnetic Fields
EN 61000-4-8:2010
Voltage Dips and Interruptions
EN 61000-4-11:2004+A1:2017
Mechanical Tests
Spring Hammer Test
IEC 62052-11:2003
Vibration Test
IEC 62052-11:2003
Shock Test
IEC 62052-11:2003
Revenue Metering Approval
NMI M6-1 of Australia
Approval Mark: NMI 14/2/109
UL Ref. # R4789222180_NMI
UL Ref. # R4789222180_NMI
Wiring Mode
Wiring Mode
PMC-340-A
PMC-340-B
100A Direct Connect Wiring
3P4W without CTs
3P3W without CTs
1P3W without CTs
3P3W without CTs
1P3W without CTs
3P4W without CTs
3P3W without CTs
1P3W without CTs
1P2W L-L without CTs
1P2W L-N without CTs
3P3W without CTs
1P3W without CTs
1P2W L-L without CTs
1P2W L-N without CTs
5A CT Connect Wiring
3P4W with 3CTs
3P3W with 3CTs
3P3W with 2CTs
1P3W with 2CTs
3P3W with 3CTs
3P3W with 2CTs
1P3W with 2CTs
3P4W with 3CTs
3P3W with 3CTs
3P3W with 2CTs
1P3W with 2CTs
1P2W L-L with 1CT
1P2W L-N with 1CT
3P3W with 3CTs
3P3W with 2CTs
1P3W with 2CTs
1P2W L-L with 1CT
1P2W L-N with 1CT
